型号 Type |
额定电压 Rated Voltage(KV) |
额定电流 Rated Current(A) |
开断电流 Breaking Current(KA) |
冲击电压 Impulse Voltage(KV) |
工频耐压 Power-frequeney Withstand Voltage(KV) |
爬距 Leakage Distance (mm) |
重量 Weight (mm) |
包装尺寸 只装(CM) |
|||||||
HRW12-15/100 | 15 | 100 | 6.3 | 110 | 42 | 372 | 4 | 47*40*12 | |||||||
HRW12-15F/100 | 57*44*14 | ||||||||||||||
HRW12-15/200 | 15 | 200 | 12.5 | 110 | 42 | 372 | 5 | 47*40*12 | |||||||
HRW12-15F/200 | 57*44*14 |
